Overview

The feature generates dimensions between grids or levels by identifying parallel elements within a selection and calculating distances between them. Dimensions are placed automatically, reducing manual measurement work.

Key Capabilities

Grids and Levels Support

The command works with both grids and levels, supporting dimensioning of horizontal levels and vertical grids based on view and project requirements.

Parallel Element Detection

The tool processes only parallel grids or levels when generating dimensions, ensuring uniform application in symmetrical layouts with repetitive spacing patterns.

View Compatibility

The command operates in any view where grids or levels are visible, including:

Plan views
Elevation views
Section views
