Create room section box
Generate 3D section box views for rooms in Revit, enabling detailed visualization of room boundaries and interior components.
Overview
The Create room section box command is a public BIMLOGIQ Copilot feature that automates 3D view generation in Revit. It helps users visualize rooms comprehensively by capturing the full extent of the room, including floors, ceilings, walls, and interior elements.
Key Features
Search and Select by Choice
Locate specific rooms using their name or number to generate corresponding 3D section boxes.
Pick by Selection
Manually select rooms within your Revit model to create section boxes for chosen spaces.
Generate for All Rooms
Automatically create 3D section boxes across your entire project — particularly useful for large-scale projects with numerous rooms.
Custom View Naming and Scaling
Assign custom names to generated views and adjust scale settings to align with your project’s naming conventions and documentation standards.
Capabilities
The command captures room extents completely, supporting better visualization and project management workflows. This functionality facilitates detailed 3D documentation suitable for architectural analysis and interior space planning.
