Overview

This command automates the creation of openings in walls and floors at cable tray intersections in Revit. It streamlines MEP and structural coordination by eliminating repetitive manual tasks while supporting advanced configuration options.

Key Features

Automatic Intersection Detection

The tool identifies where cable trays cross host elements and generates corresponding openings, reducing manual work and enhancing accuracy.

Linked Model Support

Cable trays from linked electrical models can be included to ensure proper coordination across disciplines when systems are modeled separately.

Manual Cable Tray Selection

Users can specify particular cable trays for opening creation, maintaining control over project modifications.

Flexible Application Options

Openings can be applied to walls, floors, or both depending on project requirements and construction methodology.

Adjustable Clearance Settings

Define custom gap spacing around each opening to accommodate installation tolerances during construction.

Opening Consolidation

Multiple nearby penetrations can be merged into a single opening based on a configurable merge tolerance threshold, simplifying geometry.
