Automated Grid Intersection Detection

The system scans your model based on a selected element category and determines the nearest grid intersection for each element. For example, it can automatically assign the closest intersection to Air Terminals or Structural Columns without requiring manual input.

Customizable Data Storage in Parameters

Intersection information gets written to a parameter you define, such as “Comments” or a project-specific field. This approach enables data to be easily filtered, scheduled, and referenced within the project.

Flexible Category Selection

You can specify which element category the command should process. This supports application across different disciplines and element types, including mechanical components or structural elements.
