Overview

This automation tool generates callouts for spaces in Revit views, offering multiple selection approaches and customization options for margins and naming conventions.

Flexible Space Selection

Choose from three selection methods:

Manual Selection: Pick individual spaces for targeted callout creation
View Selection: Select spaces directly within the active view
All Spaces in View: Automatically generate callouts for every visible space

Adjustable Callout Margin

Set a custom margin value in millimeters to define the distance between the space boundary and callout boundary. This accommodates different detailing standards and project preferences.

Customizable Callout Prefix

Apply a custom prefix to generated callouts to support structured naming conventions, improving organization in larger projects.
