Automating Data Export to Excel, Updating, and Importing Back into Revit Using AI with BIMLOGIQ Copilot
Use BIMLOGIQ Copilot to export floor data to Excel, update cost values externally, and import the changes back into Revit — a full round-trip takeoff workflow, automated.
In this example, BIMLOGIQ demonstrates automation of quantity takeoff data extraction and updating in Revit. The process addresses time-consuming and error-prone tasks by showing how to export floor element data to Excel, modify cost values, and reimport updated information into Revit.
Prompts
Prompt 1:
Find all floor elements in the current project and export their data to an Excel file named "takeoff.xlsx", saved on the desktop. The Excel file should have the following columns: First column: Element ID, Second column: Area (m²), Third column: Volume (m³), Fourth column: Cost parameter. Ensure that all parameter values are displayed in their respective units.Prompt 2:
Update values of Cost parameters from excel file = "takeoff.xlsx". If its Null or Read-Only, don't do anything. RELATED
